| Model | GBP24V-200AH | GBP48V-100AHR (Voltage Optional 51.2V) | GBP48V-200AH-R (Voltage Optional 51.2V) |
|---|---|---|---|
| Nominal Voltage(V) | 25.6 | 48 | |
| Nominal capacity(AH) | 210 | 105 | 210 |
| Nominal energy capacity(kwh) | 5.3 | 5 | 10 |
| Operating voltage range | 22.4-29.2 | 42-54.75 | |
| Recommended charging voltage(V) | 28 | 52.5 | |
| Recommended discharge cut-off voltage(V) | 24 | 45 | |
| Standard charging current(A) | 100 | 50 | 100 |
| Maximum continuous charging current(A) | 200 | 100 | 200 |
| Standard discharge current(A) | 100 | 50 | 100 |
| Maximum discharge current(A) | 200 | 100 | 200 |
| Applicable temperature(°C) | 30~60(Recommended 10~35) | ||
| Allowable humidity range(%rh) | 0~95% no condensation | ||
| Storage temperature(°C) | -20~65(Recommended 10~35) | ||
| Protection level | IP20 | ||
| cooling method | natural air cooling | ||
| Life cycles | 6000+ times at 80% DOD | ||
| Maximum size (DxWxH)mm | 596x545x155 | 540x545x155 | 610x510x246 |
| Weight(kg) | 48 | 44.5 | 88.3 |
Welcome to MH Energy, your trusted partner for sustainable energy solutions.We're a leading provider of premium solar PV system products and services,dedicated to delivering quality, reliability, and a greener future. Our rangeincludes solar PV modules, lithium batteries, solar inverters, and complete solarenergy systems, all harnessing the boundless power of the sun.
Quality Focus and Customer DedicationWe understand the critical role of quality and reliability in solar PV systems. Weexclusively offer tier 1 products, ensuring our clients receive top-tier solutionsmeeting the industry's strictest standards. Exceptional customer service is thecornerstone of our mission. Our seasoned professionals are committed todelivering tailored solutions for each client.
Unwavering Sustainability CommitmentOur passion is creating a positive environmental impact and building asustainable future. Through our optimal solar PV and BESS solutions, weempower clients to embrace clean energy and reduce their carbon footprint. Wefrmly believe sustainable energy is the key to a brighter future and are leadingthe charge in this green energy revolution.
